The constant growth of prices for energy and natural gas leads ordinary Ukrainians to seek alternative forms of energy. In addition, green energy is economical and environmentally friendly.

An additional incentive was the "green tariff" - a special tariff for electricity generation. Green tariff is valid for both industrial and home solar power plants that use renewable energy generation. So, in simple terms, the household receives a payment from the state for every kilowatt generated in the network.

In addition, the tariff will be valid until 2030. What will it give ordinary Ukrainians? So, imagine that you have decided to get your own energy, using solar energy. To do this, you can install a rooftop solar photovoltaic power plant to 30kW. Moreover, you get the most important thing - independence, as well as savings on payments for electricity and payback of 3-5 years. And it is quite an attractive investment.

An important role in the installation of domestic solar station plays a variety of equipment. So, you need to determine the manufacturer of solar panels, inverters and accessories. If you want your solar panels and inverter last a long time, we recommend you solar panels of Sharp. This brand needs no introduction, as the Sharp PV modules are installed in over 130 satellites 1,200 lighthouses, in road traffic and industrial applications, in public buildings and homes. Such a wide range of applications proves the fact that Sharp PV modules can be integrated into a variety of environments. In addition, the guarantee is 25 years to the model, and in the line have both polycrystalline and monocrystalline modules (power from 250 to 290 watts).

To select the inverter you should understand what the inverter is and what types of inverters are. Inverter is a device that converts direct current from the solar panels into alternating. Inverters are divided into 3 main types: network, stand-alone and hybrid (combining the characteristics of online and offline). For the construction of a green tariff SES can be used by network and hybrid inverter. Network only worka on the generation in the existing network. Standalone can operate with batteries.

Hybrid inverter combines the properties of the first two types, it is possible to construct an autonomous uninterrupted power supply system to generate a network. Because an inverter  ia a high-tech and expensive thing, it is worth buying products by proven manufacturer. The leaders in the production of inverter equipment are Western European countries. It is also important that it is a reliable and quality equipment company that has professionals capable of providing high-quality warranty, service and after sales support. Although there are many high-quality inverters, however, one of the best solutions (in terms of price quality) inverter by the Austrian company Fronius. So, this company has 23 years of experience in solar energy, and more than 1 million inverters installed worldwide. Fronius inverters are a popular choice wherever there is a solar installation. Moreover, the company "Tokmak Solar Energy" has launched a service program of 24 TSE warranty and post warranty service of inverters Fronius.

─── What steps need to be taken? ───

Step 1 - Designing

Step 2 - Installation

Step 3 - Input into operation

So, we assume that you have chosen the right equipment for you. Now you need to choose where to install solar panels. Thus, it is desirable to make the installation of solar panels on the southern slope of the roof. However, it is a valid installation of panels on the south-east or south-west. Go to the next step, which is usually done in parallel - preparing and submitting documents to the RECs and Oblenergo.

Generally the company installer assist and provides documentary support. If you, for example, host 10 kW, at the moment, you need to think about the installation. If you want to increase the installed capacity, then you need to apply to the local RES. You need to provide a passport, identification code, and legal documents, such as an agreement with the RECs and the geodesic to the copy of your land, where the household. The cost of this service can be found here.

Step 1 - Designing

Step 2 - Installation.

Step 3 - Input into operation

Installation of solar panels is a difficult and responsible task that should be performed only by specialists. Most construction works carried out at height. Also, sets of modules and mounting are heavy. That is why this should be done only by professionals. In addition, you must have permits to carry out such works. And, what is the most importantly, the installation work should be executed exclusively in accordance with the recommendations of the equipment manufacturers.

Step 1 - Designing

Step 2 - Installation.

Step 3 - Input into operation

After the installation and commissioning, you can safely make an application with a to connect it to your home SES Oblenergo. Usually, their representatives come to the object,  screen, install metering devices and sign a contract. After UTS signed, you can break to the signing of the sale and purchase of electricity from Oblenergo. The contract specifies details, which means you will be charged for the sale of surplus electricity to the grid according to the "green tariff".
